Item

P10 Single Color LED Module

Pixel pitch

10mm

Resolution(pixels)

32*16

Module Size(W*H*T,cm)

32*16*2.4

Pixel Density(dots/m2)

10,000

Pixel configuration

1R

LED type

DIP546

Red wavelength

625±2nm

Display Color

Red

Best viewing distance(m)

30

Viewing angle

110°/65°

Driving method

1/4 scan constant voltage

Brightness

>3500cd /m2

Power consumption

Max.250w/m², Ave.150w/m2

Gray scale

4096 colors

Control method

Synchronization & Asynchronization

Frame frequency

60Hz

Refresh frequency

>300Hz

Working voltage

AC220V/110V±10%

IP grade

IP65

Operating Temperature

-20°C~60°C

Life span

>100,000 hours
